DVD-4108
12G SDI 1-to-8 Single Channel Video Distribution Amplifier
The DVD-4108 is a reliable one to eight 12G/6G/3G/HD/SD-SDI video distribution amplifier. The module is equipped with a re-clocker to remove jitter and an equalizer to compensate for cable loss, which are its main features. Optionally, to ensure signal continuity in case of power failure, the input signal is routed to one of the outputs via bypass relay.
Overview
DVD-4108 is a reliable one to eight 12G/6G/3G/HD/SD-SDI video distribution amplifier. The module is equipped with a re-clocker to remove jitter and an equalizer to compensate for cable loss, which are its main features. Optionally, to ensure signal continuity in case of power failure, the input signal is routed to one of the outputs via bypass relay. The module can be easily monitored and controlled using onboard DIP switches or the web-based user interface. The front edge of the module has LED indicators that provide information about its operational status.
Features
• Dual channel operation with a robust built-in 2×2 cross-point
• Format agnostic (270 Mbps – 12 Gbps)
• Supports SMPTE ST 2082, ST 2081, 424M, 292M, and 259M standards
• Web-based user interface
• Detection of the input signal format
• Re-Clocking for jitter removal
• Cable loss compensation (12G-SDI: 80 meters, Belden 4794R)
• Hot-plug mechanism
• Transparent to ancillary and audio data
• Status LED indicators
Order Info
| product | description | type |
|---|---|---|
| DVD-4108 | Single Channel 1-to-8 12G-SDI Video Distribution Amplifier | Main Board |
| DVD-4108-3DRP-R | Double Slot Back-panel with Bypass Relay for DVD-4108 (compatible with SRM-0655) | Back-panel |
| DVD-4108-3DRP | Double Slot Back-panel for DVD-4108 (compatible with SRM-0655) | Back-panel |
| DVD-4108-3SRP-H | Single Slot Back-panel for DVD-4108 (HD-BNC Connectors, compatible with SRM-0655) | Back-panel |
Download
| Download Name | Download File |
|---|---|
| DVD-4108-Datasheet | https://www.samimgroup.com/wp-content/uploads/2025/02/Samim-DVD-4108-datasheet-en.pdf |
